Product Introduction

In pick-and-place and positioning stations the MGPM32-50 provides 50 mm of guided travel from a 32 mm bore, holding orientation precisely so downstream tooling lands where it should.

The slide-bearing guide rods restrain rotation of the moving plate, so tools, grippers and sensors mounted on it keep their orientation throughout the stroke.

The larger bore provides the rigidity needed for heavier workpiece transfer, press assists and tooling plates that are cantilevered or side-loaded.

Orders for the MGPM32-50 are produced at our factory with wholesale pricing, private label and custom stroke options available.

Key Features

MGPM32-50 compact guide cylinder with 32 mm bore and 50 mm stroke
Dual guide rods with slide bearings prevent rotation and resist lateral loads
Thin, space-saving profile reduces the mounting envelope inside machines
Port with Rc threaded connection and double-acting operation
Four mounting styles and two-direction piping for flexible layouts
Higher rigidity for heavier payloads and cantilevered tooling
Manufactured on demand with wholesale and OEM/ODM support

Applications

Heavier workpiece transfer on packaging lines
Press assist and pressing stations
Larger fixtures with cantilevered tooling plates

FAQ

Q: What is the MGPM32-50?

A: The MGPM32-50 is a 32 mm bore, 50 mm stroke compact guide pneumatic cylinder with dual guide rods, suitable for short-stroke non-rotating linear motion.

Q: What port size does the MGPM32-50 use?

A: The port uses an Rc threaded connection sized for the 32 mm bore, following the standard of the MGPM series.

Q: What kind of loads suit a 32-40 mm bore guide cylinder?

A: Larger bore models provide the rigidity for heavier workpieces, press assists and cantilevered tooling. Confirm the required load against the product spec sheet.

Q: Can you manufacture the MGPM32-50 for our order?

A: Yes. The MGPM32-50 and other MGPM series models are produced on demand with factory-direct pricing, OEM/ODM support and wholesale packaging available.

Request a Quote - Factory direct wholesale and OEM/ODM orders welcome.

Technical Specification

Parameter	Value
Model	MGPM32-50
Type	Compact guide cylinder (dual guide rod, slide bearing)
Bore size	32 mm
Stroke	50 mm
Action	Double acting
Working medium	Filtered air
Working pressure	0.15 - 1.0 MPa
Proof pressure	1.5 MPa
Operating temperature	-10 to 60 ℃
Port size	Rc threaded port (sized per bore)
Guide bearing	Slide bearing
Magnetic switch	Not included (standard)
Mounting	4 styles
Piping	2 directions
