Product Introduction

The MGPM25-30 is a 25 mm bore, 30 mm stroke compact guide pneumatic cylinder from the MGPM series, built around dual guide rods for non-rotating, high-rigidity linear motion. Its slim body makes it a common choice wherever short-stroke movement must stay straight and repeatable.

Dual guide rods carried in slide bearings prevent the tooling plate from rotating and resist lateral loads better than a plain cylinder of the same bore, keeping motion straight and repeatable over the full stroke.

With a medium bore, this model fits general assembly lines, pick-and-place units and press-fit assists, providing higher rigidity for tooling that carries side-mounted loads.

The MGPM25-30 is manufactured on demand together with other MGPM series models, with factory-direct wholesale pricing and OEM/ODM support.

Key Features

MGPM25-30 compact guide cylinder with 25 mm bore and 30 mm stroke
Dual guide rods with slide bearings prevent rotation and resist lateral loads
Thin, space-saving profile reduces the mounting envelope inside machines
Port with Rc threaded connection and double-acting operation
Four mounting styles and two-direction piping for flexible layouts
Balanced rigidity and size for general automation duties
Manufactured on demand with wholesale and OEM/ODM support

Applications

Pick-and-place on packaging equipment
Tooling fixtures with side-mounted loads
Automated handling systems requiring high rigidity

FAQ

Q: What is the MGPM25-30?

A: The MGPM25-30 is a 25 mm bore, 30 mm stroke compact guide pneumatic cylinder with dual guide rods, suitable for short-stroke non-rotating linear motion.

Q: What port size does the MGPM25-30 use?

A: The port uses an Rc threaded connection sized for the 25 mm bore, following the standard of the MGPM series.

Q: Is a 20-25 mm bore guide cylinder suitable for assembly line pick-and-place?

A: Yes. Medium-bore models are widely used for assembly line pick-and-place, clamping and press assists, offering higher rigidity for side-mounted tooling.

Q: Can you manufacture the MGPM25-30 for our order?

A: Yes. The MGPM25-30 and other MGPM series models are produced on demand with factory-direct pricing, OEM/ODM support and wholesale packaging available.

Request a Quote - Factory direct wholesale and OEM/ODM orders welcome.

Technical Specification

Parameter	Value
Model	MGPM25-30
Type	Compact guide cylinder (dual guide rod, slide bearing)
Bore size	25 mm
Stroke	30 mm
Action	Double acting
Working medium	Filtered air
Working pressure	0.15 - 1.0 MPa
Proof pressure	1.5 MPa
Operating temperature	-10 to 60 ℃
Port size	Rc threaded port (sized per bore)
Guide bearing	Slide bearing
Magnetic switch	Not included (standard)
Mounting	4 styles
Piping	2 directions
