Key Features
• MCGB-03-25-75 25 mm bore, 75 mm stroke, double acting with NBR cushioning
• Typical installations include inspection equipment at printing presses plants, where the 25 mm bore provides gentle lifting of tooling plates over the 75 mm stroke with moves without stick-slip at low speeds.
• Slide-bearing guide rods hold the tooling plate square through the full stroke
• Position sensing ready: magnetic piston plus four sensor mounting grooves
• Factory made on order with wholesale and private label support
Wide Application Scenarios
• Food processing machinery
• Semiconductor handling equipment
• Laboratory automation instruments
Common Inquiries
Q: What is the production lead time?
A: Standard models ship in 7-15 days depending on order quantity.
Q: How do you ship orders?
A: By sea, air or express (DHL/UPS/FedEx), freight prepaid or collect.
Q: Do you provide technical support?
A: Yes, drawing and application support before and after the order.
Request a Quote - Factory direct wholesale and OEM/ODM orders welcome.
Technical Specification
|
Parameter |
Value |
|
Model |
MCGB-03-25-75 |
|
Type |
Mini twin-guide cylinder, slide bearing type (03) |
|
Bore size |
25 mm |
|
Stroke |
75 mm |
|
Action |
Double acting |
|
Working medium |
Filtered air |
|
Working pressure |
0.1 - 1.0 MPa |
|
Proof pressure |
1.5 MPa |
|
Ambient temperature |
-5 to 60 ℃ |
|
Operating speed |
50 - 500 mm/s |
|
Cushion |
NBR cushion pads |
|
Port size |
Rc 1/8 |
|
Magnetic piston |
Yes (standard) |
|
Sensor grooves |
4 (embedded type switches) |
