Key Features
• MCGB-03-16-25 16 mm bore, 25 mm stroke, double acting with NBR cushioning
• For automotive parts lines, the 16 mm bore MCGB cylinder handles stable clamping moves, and its 25 mm stroke moves without stick-slip at low speeds.
• Slide-bearing guide rods hold the tooling plate square through the full stroke
• Magnetic piston as standard with four sensor grooves for position switches
• Produced on demand with OEM/ODM and wholesale packaging available
Wide Application Scenarios
• Food processing machinery
• Semiconductor handling equipment
• Laboratory automation instruments
Common Inquiries
Q: What warranty do you offer?
A: 12-month warranty against manufacturing defects.
Q: What is the minimum order quantity?
A: MOQ is flexible; typical first order 10-50 pieces and sample orders are welcome.
Q: What payment terms do you accept?
A: T/T, L/C and PayPal are accepted; terms negotiable for bulk orders.
Request a Quote - Factory direct wholesale and OEM/ODM orders welcome.
Technical Specification
|
Parameter |
Value |
|
Model |
MCGB-03-16-25 |
|
Type |
Mini twin-guide cylinder, slide bearing type (03) |
|
Bore size |
16 mm |
|
Stroke |
25 mm |
|
Action |
Double acting |
|
Working medium |
Filtered air |
|
Working pressure |
0.1 - 1.0 MPa |
|
Proof pressure |
1.5 MPa |
|
Ambient temperature |
-5 to 60 ℃ |
|
Operating speed |
50 - 500 mm/s |
|
Cushion |
NBR cushion pads |
|
Port size |
M5 x 0.8 |
|
Magnetic piston |
Yes (standard) |
|
Sensor grooves |
4 (embedded type switches) |
