Key Features
• MCGB-03-16-10 16 mm bore, 10 mm stroke, double acting with NBR cushioning
• Typical installations include packaging stations at medical device plants, where the 16 mm bore provides guided sliding movements over the 10 mm stroke with keeps the plate square under side load.
• Slide-bearing guide rods hold the tooling plate square through the full stroke
• Position sensing ready: magnetic piston plus four sensor mounting grooves
• Factory made on order with wholesale and private label support
Wide Application Scenarios
• Electronics assembly lines
• Battery manufacturing stations
• Printing and converting equipment
Common Inquiries
Q: Are these direct replacements for standard MCGB-03 parts?
A: Yes, identical mounting dimensions and port layout for direct replacement.
Q: What is the production lead time?
A: Standard models ship in 7-15 days depending on order quantity.
Q: How are the cylinders packed?
A: Export cartons with foam protection; custom packaging available.
Request a Quote - Factory direct wholesale and OEM/ODM orders welcome.
Technical Specification
|
Parameter |
Value |
|
Model |
MCGB-03-16-10 |
|
Type |
Mini twin-guide cylinder, slide bearing type (03) |
|
Bore size |
16 mm |
|
Stroke |
10 mm |
|
Action |
Double acting |
|
Working medium |
Filtered air |
|
Working pressure |
0.1 - 1.0 MPa |
|
Proof pressure |
1.5 MPa |
|
Ambient temperature |
-5 to 60 ℃ |
|
Operating speed |
50 - 500 mm/s |
|
Cushion |
NBR cushion pads |
|
Port size |
M5 x 0.8 |
|
Magnetic piston |
Yes (standard) |
|
Sensor grooves |
4 (embedded type switches) |
