SY9320 series solenoid valve adopts a novel pilot valve structure, which improves the reversing performance of the valve body and increases the reset ability, so the reliability of the solenoid valve is high.SY9320solenoid valve has short response time and good water resistance.
●SY7220 Pneumatic solenoid valve Widely used in the area of food, machine, petrochemical industry and others
●SY7220 Pneumatic solenoid valve body is processed by CNC to make it fine
●Special processing to ensure bore good friction resistance and low starting pressure
●The sealing ring is made of NBR by Mitsubishi with good performance and long service life
| Series | SY3000 | SY5000 | SY7000 | SY9000 | ||||
| Fluid | Air | |||||||
| Internal pilot Operating pressure range(Mpa) | 2 position single | 0.15 to 0.7 | ||||||
| 2 position double | 0.1 to 0.7 | |||||||
| 3 positon | 0.2 to 0.7 | |||||||
| Ambient and fluid temperature（℃） | -10 to 50 (not freezing) | |||||||
| Max. operating frequency (Hz) | 2 position single,double | 10 | 5 | 5 | 5 | |||
| 3 position | 3 | 3 | 3 | 3 | ||||
| Manual override(Manual operation) | Non-locking push type Push-turn locking slotted type Push-turn locking lever typ | |||||||
| Pilot exhaust method | Common exhaust type for main and pilot valve | |||||||
| Lubrication | Not required | |||||||
| Mounting orientation | Unrestricted | |||||||
| Impact /Vibration resistance(m/s²） | 150/30 | |||||||
| Enclosure | Dust proof(DIN termianl and M8 connector:IP 65) | |||||||
|
|
|
| C4/C6/C8 | Enameled wire (ELEKTRISOLA) | Rubber seal ring (Mitsubishi) |
|
|
|
1.Q:How can I get the sample to check your quality?
A:For multiple pieces, after price confirmation, you can require samples to check the quality. If you just need a few pieces we will provide them for free as long as you afford the express freight.
2.Q:What shipping ways our use?
A:We use UPS or DHL to ship the products. If you do not need products urgently, we will also use FEDEX and TNT.If the products are of heavy weight and large volume, we will ship them by sea.
3.Q:Are you a factory or trading company?
A:We are the leading manufacturer of pneumatic products with over 10 years experience. In the civil market , we have agencies in 5 cities and provinces. We also supply and to other local professional cylinder or air equipment manufacturer.
