The SY5520 series 3 position pressure center.C4 C6 C8 for choose.
●SY5520 The sealing ring is made of NBR by Mitsubishi with good performance and long service life
●SY5520 1.2W low power coil- Energy saving and non-pollution
●SY5520 High-precision pilot accessories . Excitation time for only 0.05 seconds
●SY5520 Embedded copper nut not easy to loose
| Series | SY3000 | SY5000 | SY7000 | SY9000 | ||||
| Fluid | Air | |||||||
| Internal pilot Operating pressure range(Mpa) | 2 position single | 0.15 to 0.7 | ||||||
| 2 position double | 0.1 to 0.7 | |||||||
| 3 positon | 0.2 to 0.7 | |||||||
| Ambient and fluid temperature（℃） | -10 to 50 (not freezing) | |||||||
| Max. operating frequency (Hz) | 2 position single,double | 10 | 5 | 5 | 5 | |||
| 3 position | 3 | 3 | 3 | 3 | ||||
| Manual override(Manual operation) | Non-locking push type Push-turn locking slotted type Push-turn locking lever typ | |||||||
| Pilot exhaust method | Common exhaust type for main and pilot valve | |||||||
| Lubrication | Not required | |||||||
| Mounting orientation | Unrestricted | |||||||
| Impact /Vibration resistance(m/s²） | 150/30 | |||||||
| Enclosure | Dust proof(DIN termianl and M8 connector:IP 65) | |||||||
|
|
|
| C4/C6/C8 | Enameled wire (ELEKTRISOLA) | Rubber seal ring (Mitsubishi) |
|
|
|
1.Q:Can I get sample?
A:Yes,We can offer free sample but express charge by your side. For any needs feel free to contact us.
2.Q:Can I buy 1pc sample first and small order ?
A:Of course, we support sample order and small order, especially for new customers under certain condition.
3.Q:What's the response time of sales?
A:Within 24 hour
4.Q:Delivery time
A:By Express：5-10 days By Sea: 20-30 days
Hot Tags: sy5520, China, suppliers, manufacturers, factory, custom, wholesale, SY5120 5DZ C8, SY5120 5G 01, SY5120 5G C6, SY5120 5L 01, SY5220 5LZD C8, SY5320 5LZD C6
