SY5220-5DZ-C6 Pneumatic solenoid valves are versatile performers, but choosing the right one is key to a harmonious symphony in your air-powered systems. With the right knowledge and a bit of guidance, you can find the perfect valve to conduct your air flow with precision and efficiency.
|
Series |
SY3000 |
SY5000 |
SY7000 |
SY9000 |
|
|
Fluid |
Air |
||||
|
Internal pilot |
2 position single |
0.15 to 0.7 |
|||
|
2 position double |
0.1 to 0.7 |
||||
|
3 position |
0.2 to 0.7 |
||||
|
Ambient and fluid temperature (C) |
-10 to 50 (No freezing) |
||||
|
Max.operating |
2 position single,double |
10 |
5 |
5 |
5 |
|
3 position |
3 |
3 |
3 |
3 |
|
|
Manual override (Manual operation) |
Non-locking push type |
||||
|
Pilot exhaust method |
Common exhaust type for main and pilot valve |
||||
|
Lubrication |
Not required |
||||
|
Mounting orientation |
Unrestricted |
||||
|
Impact/Vibration resistance(m/s²)Note) |
150/30 |
||||
|
Enclosure |
Dust proof (*DIN terminal and M8 connector:IP65) |
||||
