SY3000 Solenoid Valve: Ultra-Compact & High-Performance 5-Port Solution
Engineered for demanding industrial automation, the SY3000 solenoid valve stands out as the smallest model in the SMC SY series. Its ultra-compact design is the key to seamless integration in space-constrained environments, delivering stable performance for controlling pneumatic actuators and cylinders without compromise.
Beyond its size advantage, the SY3000 series delivers exceptional energy efficiency and reliable operation, critical for optimizing automated systems. Built with robust, corrosion-resistant materials, these valves ensure extended durability even under harsh operating conditions.
Experience enhanced process efficiency thanks to the SY3000's fast response times and precise flow control, adaptable across a wide range of applications. Furthermore, user-friendly installation and maintenance procedures significantly reduce downtime and operational costs, maximizing your productivity.
|
How to Order SY Series Pneumatic Solenoid Valve |
||||
|
SY5(Ⅰ)1(Ⅱ)20-5(Ⅲ)L(Ⅳ)□(Ⅴ)□(Ⅵ)-01 |
||||
|
Ⅰ. SERIES |
Ⅱ. TYPE OF ACTUATION |
|||
|
3 |
SY3000 |
1 |
2 position single |
|
|
5 |
SY5000 |
2 |
2 position double |
|
|
7 |
SY7000 |
3 |
3 position closed center |
|
|
9 |
SY9000 |
4 |
3 position exhaust center |
|
|
5 |
3 position pressure center |
|||
|
Ⅲ. RATED VOLTAGE |
Ⅵ.Manual override |
|||
|
1 |
100 VAC |
Nil:Non |
||
|
2 |
110 VAC |
locking push type |
||
|
3 |
110 VAC [115 VAC] |
D:Push-turn |
||
|
4 |
220 VAC [230 VAC] |
locking slotted type |
||
|
5 |
24 VDC |
E:Push-turn |
||
|
6 |
12 VDC |
locking lever type |
||
|
Ⅳ. ELECTRICAL ENTRY |
||||
|
G |
Lead wire length 300 mm |
L |
With lead wire (Length 300mm) |
|
|
H |
Lead wire length 600 mm |
LN |
Without lead wire |
|
|
MO |
Without connector |
LO |
Without connector |
|
|
M |
With lead wire (Length 300 mm) |
D,Y |
With connector |
|
|
MN |
Without lead wire |
DO,YO |
Without connector |
|
|
Ⅴ.Light/Surge voltage suppressor |
||||
|
Electrical entry for G,H,L,M,W |
Electrical entry for D,Y |
|||
|
Nil |
Without light/surge voltage suppressor |
Nil |
Without light/surge voltage suppressor |
|
|
S |
With surge voltage suppressor |
S |
With surge voltage suppressor |
With surge voltage suppressor |
|
(Non-polar type) |
(Non-polar type) |
|||
|
Z |
With light/surge voltage suppressor |
Z |
With light/surge voltage suppressor |
|
|
(Non-polar type) |
||||
|
R |
With surge voltage suppressor (Non-polar type) |
DOZ and YOZ are not available. |
||
|
U |
With lightlsurge voltage suppressor (Non-polar type) |
For AC voltage valves there is no |
||
SY Series Pneumatic Solenoid Valve Technical Parameters
|
SY Series Pneumatic Solenoid Valve Key Specifications |
|||||
|
Series |
SY3000 |
SY5000 |
SY7000 |
SY9000 |
|
|
Fluid |
Air |
||||
|
Internal pilot |
2 position single |
0.15 to 0.7 |
|||
|
2 position double |
0.1 to 0.7 |
||||
|
3 position |
0.2 to 0.7 |
||||
|
Ambient and fluid temperature(C) |
-10 to 50(No freezing) |
||||
|
Max.operating |
2 position single,double |
10 |
5 |
5 |
5 |
|
3 position |
3 |
3 |
3 |
3 |
|
|
Manual override(Manual operation) |
Non-locking push type, |
||||
|
Pilot exhaust method |
Common exhaust type for main and pilot valve |
||||
|
Lubrication |
Not required |
||||
|
Mounting orientation |
Unrestricted |
||||
|
Impact/Vibration resistance(m/s²)Note) |
150/30 |
||||
|
Enclosure |
Dust proof(*DIN terminal and M8 connector:IP65) |
||||
SMC SY3000 Series Solenoid Valve Model List
Below is the complete list of SMC SY3000 series solenoid valve models. Please contact us for detailed specifications and pricing.
|
SY3120-6L-M5 |
SY3120-5L-M5 |
SY3120-4L-M5 |
SY3120-6L-C4 |
SY3120-5L-C4 |
SY3120-4L-C4 |
|
SY3220-6L-M5 |
SY3220-5L-M5 |
SY3220-4L-M5 |
SY3220-6L-C4 |
SY3220-5L-C4 |
SY3220-4L-C4 |
|
SY3320-6L-M5 |
SY3320-5L-M5 |
SY3320-4L-M5 |
SY3320-6L-C4 |
SY3320-5L-C4 |
SY3320-4L-C4 |
|
SY3420-6L-M5 |
SY3420-5L-M5 |
SY3420-4L-M5 |
SY3420-6L-C4 |
SY3420-5L-C4 |
SY3420-4L-C4 |
|
SY3520-6L-M5 |
SY3520-5L-M5 |
SY3520-4L-M5 |
SY3520-6L-C4 |
SY3520-5L-C4 |
SY3520-4L-C4 |
|
SY3120-6G-M5 |
SY3120-5G-M5 |
SY3120-4G-M5 |
SY3120-6G-C4 |
SY3120-5G-C4 |
SY3120-4G-C4 |
|
SY3220-6G-M5 |
SY3220-5G-M5 |
SY3220-4G-M5 |
SY3220-6G-C4 |
SY3220-5G-C4 |
SY3220-4G-C4 |
|
SY3320-6G-M5 |
SY3320-5G-M5 |
SY3320-4G-M5 |
SY3320-6G-C4 |
SY3320-5G-C4 |
SY3320-4G-C4 |
|
SY3420-6G-M5 |
SY3420-5G-M5 |
SY3420-4G-M5 |
SY3420-6G-C4 |
SY3420-5G-C4 |
SY3420-4G-C4 |
|
SY3520-6G-M5 |
SY3520-5G-M5 |
SY3520-4G-M5 |
SY3520-6G-C4 |
SY3520-5G-C4 |
SY3520-4G-C4 |
