Airtac type 4V210 series pneumatic solenoid valves

The Airtac type 4V200 solenoid air valve series is a functional replacement for the SMC VFS2000 series.

Product Features:
1. Pilot-oriented mode: optional for internal or external;
2. Structure in sliding column mode: good tightness and sensitive reaction;
3. Three position Solenoid Air Valves have three kinds of central function for your choice;
4. Double control Solenoid Air Valves have memory function;
5. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life;
6. No need to add oil for lubrication;
7. It is available to form integrated valve group with the base to save installation space;
8. Affiliated manual devices are equipped to facilitate installation and debugging;
9. Several standard voltage grades are optional;

Coil specification

Item specification
Standard voltage	AC220V	AC110V	AC24V	DC24V	DC12V
Scope of voltage	AC: ±15% DC: ±10%
Power consumption	4.5VA	4.5VA	5.0VA	3.0W	3.0W
Protection	IP65(DIN40050)
Temperature classification	B Class
Electrical entry	Terminal, Grommet
Activating time	0.05 sec and below

airtac type 4v210

4V210-01

pneumatic-valves

High Frequency Guide

Pure Copper High Precision Pilot Head Up To 5 Times/second Air Valve Precision, Smooth Without Stuttering. wide Application Range, High Sensitivity. the Use Of Sufficient Red Copper Coils, Long - Term Use Is Not Easy To Hot.

Simple Function Diagram

Power Supply: Intake Port P is Vented to Vent Port B, Vent Port a is Vented to Exhuast Port R.

No Power: Intake Port P Ventilation Vent Port A, Vent Port B Ventilation Exhuast Port S.

Functional Analysis: Realize One Opening and One Closing

Waterproof Box Coil Cover

The Coil Cover Of The Waterproof Box Is Used To Prevent Water From Falling Onto The Coil During The Working Process, Resulting In The Failure To Work Properly.
