AIRTAC 4V410-15 Solenoid Valve

Range of Configurations for 4V410-15 Solenoid Valve:

The 4V410-15 Solenoid Valve is available in various configurations, such as 2-way and 3-way valves. They can be customized as normally open (NO) or normally closed (NC) based on specific application needs.

Item	specification
Standard voltage	AC220V	AC110V	AC24V	DC24V	DC12V
Scope of voltage	AC:±15% DC:±10%
Power consumption	3.5VA	3.5VA	4.0VA	2.5W	2.5W
Protection	IP65(DIN40050)
Temperature classification	B Class
Electrical entry	Terminal,Grommet
Activating time	0.05 sec and below

Model	Code	Valve type	Port size	Voltage	Electrical entry	Thread type
4V:Solenoid valve (5/2,5/3 way)	1:100 Series	10:Single solenoid 5/2 way 20:Double solenoid 5/2 way 30C:Double solenoid 5/3 way closed center 30E:Double solenoid 5/3 way exhaust center 30P:Double solenoid 5/3 way pressure center	M5:M5	A:AC220V B:DC24V C:AC110V E:AC24V F:DC12V	Blank:Terminal I:Grommet	No this code
			06:1/8"			Blank·PT G:G T:NPT
