Ordering code
|
Model
|
4V310-08
4V320-08 |
4V330C-08
4V330E-08 4V330P-08 |
4V310-10
4V320-10 |
4V330C-10
4V330E-10 4V330P-10 |
|
Fluid
|
Air(to be filtered by 40μm filter element)
|
|||
|
Acting
|
Internal pilot or external pilot
|
|||
|
Port size[Note1]
|
In=Out=Exhaust=1/4"
|
In=Out=3/8"Exhaust=1/4"
|
||
|
Orifice size
|
25.0mm²
(Cv=1.40) |
18.0mm²
(Cv=1.00) |
30.0mm²
(Cv=1.68) |
18.0mm²
(Cv=1.00) |
|
Valve type
|
5 port 2 position
|
5 port 3 position
|
5 port 2 position
|
5 port 3 position
|
|
Operating pressure
|
0.15~0.8MPa(21~114psi)
|
|||
|
Proof pressure
|
1.2MPa(175psi)
|
|||
|
Temperature
|
-20~70℃
|
|||
|
Material of body
|
Aluminum alloy
|
|||
|
Lubrication[Note2]
|
Not required
|
|||
|
Max.frequency [Note3]
|
4 cycle/sec
|
3 cycle/sec
|
4 cycle/sec
|
3 cycle/sec
|
|
Weight(g)
|
4V310-08:310
4V320-08:400 |
450
|
4V310-10:310
4V320-10:400 |
450
|
Features:
1.Pilot-oriented mode: internal pilot or external pilot.
2.Structure in sliding column mode: good tightness andsensitive reaction .
3.Three position solenoid valves have three kinds of centralfunction for your choice.
4.Double control solenoid valves have memory function
5.Internal hole adopts special processing technologywhich has little attrition friction,low start pressure andlong service life.
6. No need to add oil for lubrication.
7.lt is available to form integrated valve group with the baseto save installation space.
8.Affiliated manual devices are equipped to facilitateinstallation and debugging.
9.Several standard voltage grades are optional.
