Our CQ2 series compact pneumatic cylinders follow the ISO 15552 (formerly ISO 6431) standard and represent one of the industry's most versatile actuators. With bore sizes ranging from 12 mm to 200 mm and a newly redesigned body that is 5–13% lighter, CQ2 cylinders offer unmatched flexibility for automation systems.
Thanks to its ultra-short overall length and four surface auto-switch grooves, CQ2 delivers precise linear motion without interference from mounted sensors. The standard male or female rod-thread design ensures compatibility, while optional mounting variations (C-clevis, foot, flange) meet diverse installation needs. Ideal for packaging automation, robotic EOAT systems, pick-and-place units, and ergonomic fixture designs.
|
How to Order CQ2 Series Pneumatic Cylinder |
|||||
|
CQ2 |
B |
6 |
10 |
D |
M |
|
CDQ2:with magnet |
Mounting |
Bore size |
Cylinder Stroke |
Action |
Body option |
|
B:Through-hole/Head |
4 |
5 10 |
D:Double acting |
Nil:Rod end female thread |
|
|
6 |
15 20 |
C:With rubber bumper |
|||
|
10 |
25 30 |
M:Rod end male thread |
|||
Need a high-performance compact actuator for your automation design?
Our CQ2 Series Double-Acting Cylinders offer ISO compatibility, ultra-compact size, sensor-mount flexibility, and extensive bore options.
OEM/ODM customization available
Fast global delivery
Contact us today for datasheets, CAD drawings, and your custom quote!
|
Specifications |
|||||
|
Pneumatic type |
|||||
|
Bore size [mm] |
4 |
6 |
10 |
||
|
Action |
Double acting,Single rod |
||||
|
Fluid |
Air |
||||
|
Proof pressure |
1.0 MPa |
||||
|
Maximum operating pressure |
0.7 MPa |
||||
|
Minimum operating pressure |
0.15 MPa |
0.1 MPa |
|||
|
Ambient and fluid temperatures |
Without auto switch magnet:-10 to 70℃ |
No freezing |
|||
|
Lubrication |
Not required(Non-lube) |
||||
|
Piston speed |
50 to 500 mm/s |
||||
|
Allowable kinetic |
Without cushion |
0.9×10-3 |
2.2x10-3 |
5.9×10-3 |
|
|
With rubber bumper |
7.5×10-3 |
12.0×10-3 |
51.6×10-3 |
||
|
Stroke length tolerance |
+1.0 mm*1 |
||||
|
Series Model |
Available Models |
|
CQ2B12 Series |
CQ2B12-5D, CQ2B12-10D, CQ2B12-15D, CQ2B12-20D, CQ2B12-25D, CQ2B12-30D, CQ2B12-35D, CQ2B12-40D, CQ2B12-45D, CQ2B12-50D, CQ2B12-55D, CQ2B12-60D |
|
CQ2B16 Series |
CQ2B16-5D, CQ2B16-10D, CQ2B16-15D, CQ2B16-20D, CQ2B16-25D, CQ2B16-30D, CQ2B16-35D, CQ2B16-40D, CQ2B16-45D, CQ2B16-50D, CQ2B16-55D, CQ2B16-60D |
|
CQ2B20 Series |
CQ2B20-5D, CQ2B20-10D, CQ2B20-15D, CQ2B20-20D, CQ2B20-25D, CQ2B20-30D, CQ2B20-35D, CQ2B20-40D, CQ2B20-45D, CQ2B20-50D, CQ2B20-55D, CQ2B20-60D |
|
CQ2B25 Series |
CQ2B25-5D, CQ2B25-10D, CQ2B25-15D, CQ2B25-20D, CQ2B25-25D, CQ2B25-30D, CQ2B25-35D, CQ2B25-40D, CQ2B25-45D, CQ2B25-50D, CQ2B25-55D, CQ2B25-60D |
|
CQ2B32 Series |
CQ2B32-5D, CQ2B32-10D, CQ2B32-15D, CQ2B32-20D, CQ2B32-25D, CQ2B32-30D, CQ2B32-35D, CQ2B32-40D, CQ2B32-45D, CQ2B32-50D, CQ2B32-55D, CQ2B32-60D, CQ2B32-65D, CQ2B32-70D, CQ2B32-75D, CQ2B32-80D |
|
CQ2B40 Series |
CQ2B40-5D, CQ2B40-10D, CQ2B40-15D, CQ2B40-20D, CQ2B40-25D, CQ2B40-30D, CQ2B40-35D, CQ2B40-40D, CQ2B40-45D, CQ2B40-50D, CQ2B40-55D, CQ2B40-60D, CQ2B40-65D, CQ2B40-70D, CQ2B40-75D, CQ2B40-80D |
|
CQ2B50 Series |
CQ2B50-5D, CQ2B50-10D, CQ2B50-15D, CQ2B50-20D, CQ2B50-25D, CQ2B50-30D, CQ2B50-35D, CQ2B50-40D, CQ2B50-45D, CQ2B50-50D, CQ2B50-55D, CQ2B50-60D, CQ2B50-65D, CQ2B50-70D, CQ2B50-75D, CQ2B50-80D |
|
CQ2B63 Series |
CQ2B63-5D, CQ2B63-10D, CQ2B63-15D, CQ2B63-20D, CQ2B63-25D, CQ2B63-30D, CQ2B63-35D, CQ2B63-40D, CQ2B63-45D, CQ2B63-50D, CQ2B63-55D, CQ2B63-60D, CQ2B63-65D, CQ2B63-70D, CQ2B63-75D, CQ2B63-80D |
|
CQ2B80 Series |
CQ2B80-5D, CQ2B80-10D, CQ2B80-15D, CQ2B80-20D, CQ2B80-25D, CQ2B80-30D, CQ2B80-35D, CQ2B80-40D, CQ2B80-45D, CQ2B80-50D, CQ2B80-55D, CQ2B80-60D, CQ2B80-65D, CQ2B80-70D, CQ2B80-75D, CQ2B80-80D |
|
Series Model |
Available Models |
|
CDQ2B12 Series |
CDQ2B12-5D, CDQ2B12-10D, CDQ2B12-15D, CDQ2B12-20D, CDQ2B12-25D, CDQ2B12-30D, CDQ2B12-35D, CDQ2B12-40D, CDQ2B12-45D, CDQ2B12-50D, CDQ2B12-55D, CDQ2B12-60D |
|
CDQ2B16 Series |
CDQ2B16-5D, CDQ2B16-10D, CDQ2B16-15D, CDQ2B16-20D, CDQ2B16-25D, CDQ2B16-30D, CDQ2B16-35D, CDQ2B16-40D, CDQ2B16-45D, CDQ2B16-50D, CDQ2B16-55D, CDQ2B16-60D |
|
CDQ2B20 Series |
CDQ2B20-5D, CDQ2B20-10D, CDQ2B20-15D, CDQ2B20-20D, CDQ2B20-25D, CDQ2B20-30D, CDQ2B20-35D, CDQ2B20-40D, CDQ2B20-45D, CDQ2B20-50D, CDQ2B20-55D, CDQ2B20-60D |
|
CDQ2B25 Series |
CDQ2B25-5D, CDQ2B25-10D, CDQ2B25-15D, CDQ2B25-20D, CDQ2B25-25D, CDQ2B25-30D, CDQ2B25-35D, CDQ2B25-40D, CDQ2B25-45D, CDQ2B25-50D, CDQ2B25-55D, CDQ2B25-60D |
|
CDQ2B32 Series |
CDQ2B32-5D, CDQ2B32-10D, CDQ2B32-15D, CDQ2B32-20D, CDQ2B32-25D, CDQ2B32-30D, CDQ2B32-35D, CDQ2B32-40D, CDQ2B32-45D, CDQ2B32-50D, CDQ2B32-55D, CDQ2B32-60D, CDQ2B32-65D, CDQ2B32-70D, CDQ2B32-75D, CDQ2B32-80D |
|
CDQ2B40 Series |
CDQ2B40-5D, CDQ2B40-10D, CDQ2B40-15D, CDQ2B40-20D, CDQ2B40-25D, CDQ2B40-30D, CDQ2B40-35D, CDQ2B40-40D, CDQ2B40-45D, CDQ2B40-50D, CDQ2B40-55D, CDQ2B40-60D, CDQ2B40-65D, CDQ2B40-70D, CDQ2B40-75D, CDQ2B40-80D |
|
CDQ2B50 Series |
CDQ2B50-5D, CDQ2B50-10D, CDQ2B50-15D, CDQ2B50-20D, CDQ2B50-25D, CDQ2B50-30D, CDQ2B50-35D, CDQ2B50-40D, CDQ2B50-45D, CDQ2B50-50D, CDQ2B50-55D, CDQ2B50-60D, CDQ2B50-65D, CDQ2B50-70D, CDQ2B50-75D, CDQ2B50-80D |
|
CDQ2B63 Series |
CDQ2B63-5D, CDQ2B63-10D, CDQ2B63-15D, CDQ2B63-20D, CDQ2B63-25D, CDQ2B63-30D, CDQ2B63-35D, CDQ2B63-40D, CDQ2B63-45D, CDQ2B63-50D, CDQ2B63-55D, CDQ2B63-60D, CDQ2B63-65D, CDQ2B63-70D, CDQ2B63-75D, CDQ2B63-80D |
|
CDQ2B80 Series |
CDQ2B80-5D, CDQ2B80-10D, CDQ2B80-15D, CDQ2B80-20D, CDQ2B80-25D, CDQ2B80-30D, CDQ2B80-35D, CDQ2B80-40D, CDQ2B80-45D, CDQ2B80-50D, CDQ2B80-55D, CDQ2B80-60D, CDQ2B80-65D, CDQ2B80-70D, CDQ2B80-75D, CDQ2B80-80D |
