SY7520 series solenoid valve 3 position pressure center Flow rate characteristics 4/2→5/3（A/B→EA/EB） b 0.27

●SY7520 Up to 80 million times of service life

●SY7520 High-strength aluminum alloy button cover

●High-precision pilot accessories . Excitation time for only 0.05 seconds

●Valve body is processed by CNC to make it fine

Series		SY3000	SY5000	SY7000	SY9000
Fluid		Air
Internal pilot Operating pressure range(Mpa)	2 position single	0.15 to 0.7
	2 position double	0.1 to 0.7
	3 positon	0.2 to 0.7
Ambient and fluid temperature（℃）	-10 to 50 (not freezing)

Max. operating frequency (Hz)	2 position single,double	10	5	5	5
	3 position	3	3	3	3
Manual override(Manual operation)	Non-locking push type Push-turn locking slotted type Push-turn locking lever typ


Pilot exhaust method	Common exhaust type for main and pilot valve

Lubrication	Not required
Mounting orientation	Unrestricted

Impact /Vibration resistance(m/s²）	150/30

Enclosure	Dust proof(DIN termianl and M8 connector:IP 65)
